Unleash the FieldLink SID-01
The FieldLink SID-01 Morse Code Station Identification Module from Red's Engineering delivers a seamless, FCC-compliant solution for Ham and GMRS radio operators. Designed to work in conjunction with the BaoFeng UV-5R and compatible radios, this compact module automates station identification via Morse code, monitoring carrier detect on a specific frequency to provide station ID for your repeater system. Its rugged, shield-type enclosure and low-power design make it ideal for both field and stationary use. Configure your callsign and intervals easily through a web-based interface on your smartphone, with OTA firmware updates to keep your module current. Handcrafted in New Hampshire, USA, the SID-01 ensures reliability and compliance, enhancing your communication experience across any GMRS or Ham radio setup.
Specifications
| Feature | Details |
|---|---|
| Model | SID-01 Morse Code Station Identification Module |
| Compatibility | Works with all repeaters and Ham/GMRS radios |
| Power Supply | USB Power (5V) |
| Power Consumption | Low-power design, <0.5W standby |
| Enclosure | Shield-type, high-impact FRS, rugged and compact |
| Dimensions | 4" x 2.5" x 1.2" (L x W x H) |
| Weight | 0.8 lbs |
| Compatibility | Works with all repeater and radio systems |
| Configuration | Web-based via smartphone (WiFi) |
| Identification Interval | Customizable (e.g., 10, 15, or 30 minutes) |
| Scheduling | Integrated RTC for sheduling identifications |
| Firmware Updates | Over-the-Air (OTA) via WiFi |
| Indicators | LED status indicators |
| Triggers | External trigger, 5-12V input and relay closure options |
| Network Compatibility | WiFi triggering coming soon |
| Carrier Monitoring | Carrier detect and loss of carrier on any specified frequency |
| Connectors | Plug-and-play audio and power connectors included |
| Origin | Handcrafted in New Hampshire, USA |
Stay Compliant, Stay Connected. Secure your FieldLink SID-01 today and simplify your station identification process.
Coming Soon
